Incoloy 925 Nickel Base Alloy Round Bar with High Purity

Basic Info.

Model NO.	Incoloy 925
Special Use	Chemical and Petrochemical Processing
Application	Superheater and Reheater Pipes in Power Plants
Transport Package	Standard Sea-Worthy Package or as Required
Specification	Diameter: 4-50mm, Length: 2000-5000mm
Trademark	Hengrui
Origin	Made in China
HS Code	7505120000
Production Capacity	50000 Tons Annually

Product Description

Product Description

Incoloy925 alloy (UNS N09925) is a precipitation hardenable alloy added with elements such as molybdenum, copper, titanium and aluminum on the basis of iron-nickel-chromium alloy.
The alloy has high strength and excellent corrosion resistance in applications.
The content of nickel is sufficient to protect the alloy from chloride ion corrosion and cracking.
The combination of nickel, molybdenum and copper also makes the alloy excellent resistance to reducing chemical components.
Molybdenum helps improve pitting and crevice corrosion resistance.
The chromium component in the alloy provides oxidation resistance to reducing environments.
The addition of titanium and aluminum can strengthen the alloy during the heat treatment process.
Similar Grades
UNS N09925, Nickel 925
Chemical Composition(%)
C ≤ 0.03
Mn ≤ 1.0
Si ≤ 0.5
S ≤ 0.03
Nb ≤ 0.5
Cu = 1.5~3.0
Al = 0.1~0.5
Ti = 1.9~2.4
Mo = 2.5~3.5
Ni = 42.0~46.0
Cr = 19.5~22.5
Fe ≥ 22
Physical properties:
Density: 8.14g/cm3.
Melting point: 1343°C.
The minimum mechanical properties of the alloy at room temperature:
The tensile strength: 650RmN/mm2.
The yield strength: 295 (RP0.2N/mm2).
Elongation rate A5%: 30.
